4JH110 Overview

Specifications

Rated Output	80.9 kW / 110mhp
Rated Speed	3200 rpm
Displacement	2 L / 122 cu. in
No. of Cylinders	4 Cylinders
Cylinder Bore x Stroke	84 mm x 90 mm / 3.31 in x 3.54 in
Combustion System	Direct Injection, Bosch Common Rail System
Aspiration	Turbocharged & Intercooled
Alternator	12V - 125A
Dry Weight Without Gear	229 kg / 505 Ibs
Dimensions	909 mm x 613 mm x 675 mm
Controls	Mechanical (Optional - VC10 System)
Certifications	RCD 2 \| EPA Tier 3 \| EPA Tier 3C \| BSO II \| EMC \| SOLAS

NOTE:

1 kW = 1.3596 mhp = 1.34102 bhp

Fuel condition: at 15°C =0.842 g/cm³

Technical data according to (ISO 8665) / (ISO3046)

Fuel temperature 40°C at the inlet of the fuel injection pump (ISO 8665)

Length includes KM35A marine gear

(Dimensions may vary with other gears/ elbow)
