8LV320 Overview

Specifications

Rated Output	235 kW / 320 mhp
Rated Speed	3800 rpm
Displacement	4.46 L / 272 cu. in
No. of Cylinders	8 Cylinders
Cylinder Bore x Stroke	86 mm x 96 mm / 3.38 in x 3.78 in
Combustion System	Direct Injection, Denso Common Rail System
Aspiration	Twin Turbocharged & Intercooled
Alternator	12V - 180A
Dry Weight Without Gear	435 kg / 959 Ibs
Dimensions	1340 mm x 880 mm x 766 mm
Controls	Electronic
Certifications	RCD 2 \| IMO Tier 2 \| EPA Tier 3 \| EPA Tier 3C \| BSO II \| EMC \| SOLAS \|
